Brand: PValley
Model: MWB-215S8
Country of Origin: China
Assemble/ Manufacturer: China
Technical Specification
- Communication using the Microwave system
- Measurement in Microwave system
- FSK Modulation & Demodulation in Microwave ban
- File transfer and data transmission
- Understanding of the micro strip design line theory
- Understanding the basic theory of microwave devices
- Design and simulation of Microwave devices
- Experiment in manufacturing and measurement of microwave devices
- Frequency Band: 2.4 GHz ~ 2.5 GHz
- Modulation: FSK
- Bit Rate: 4800~14400 bps
- Output Power: + 4.5 dBm Max.
- Impedance: 50 ohm
- Substrate Material: Rogers RO4003C
- PCB thickness: 0.508mm
- Dielectric constant: 3.38
- Low Noise Amplifier: (Gain: 26dB, Noise figure: 2.5dB, Input: P1dBm)
- Power Divider: (Type: 2-way Wilkinson,
- Return Loss: 14dB,
- Insertion Loss: 0.5dB)
- Band Pass Filter (2.4GHz): (Type: Edge-coupled, Return Loss: 10dB, Insertion Loss: 7.0dB)
- Band Pass Filter (2.5GHz): (Type: Edge-coupled, Return Loss: 10dB, Insertion Loss: 7.0dB)
- RF Amplifier: (Gain: 15dB, Input: -5dBm)
- Antenna (Transmitting & Receiving): (Type: Yagi, Gain: 9dB, VSWR: 1.5:1)
Standard Accessories
- Power Cord
- Male to Male Banana Connector
- Experiment Manual and Instructor’s Manual
- 5 Days In-House Training
Protection:
Under voltage, Supply over voltage, Thermal, Short Circuit etc.
 Warranty: 01 Years with services
