Brand: PValley
Model: PV56LD05F
Country of origin: China
Assemble/Manufacturer: Bangladesh
Technical Specification:
Features
- Transmitter with selectable frequency conversion
- Simultaneous communication of three different signals
- Communicate: Audio, Video, Digital data, PC data, Tone, Voice, function generator waveforms, etc.
- 2414–2468 MHz PLL microwave operation
- Communication of external broadband digital signal
- Choice of different transmitting and receiving frequencies
- Built-in speaker and microphone for Voice and Audio link
- Remote detection of light intensity and environment temperature
- Detachable dish antenna at each station
- USB port for PC communication
Power Supply
- Input Voltage: AC 220V ~ 240V
- Input Frequency: 50/60 Hz
- Power consumption as per module specifications
Uplink Transmitter
- Transmitter with selectable frequency conversion: 2450–2468 MHz up-linking selectable frequencies
- Wide band RF amplifier, no manual matching required
- Bandwidth: 16 MHz
- Frequency select switch and LED indication
- FM Modulation of Audio and Video
- Coverage area: 35m indoor, 100m outdoor
- Transmit: Audio, Video, Digital data, PC data, Tone, Voice, function generator waveforms, etc.
- Separate section for telemetry operation
Receiver Unit
- Receiver with selectable frequency conversion
- Frequency select switch and LED indication
- FM Demodulation of Audio and Video
- Display and monitor received signals
- Separate section for telemetry signal reception
- Detachable dish antenna for signal reception
- USB port for PC data reception
Experiments / Functionalities
- Uplink and downlink communication of Audio and Video
- Transmission and reception of Digital data, PC data, Tone, and Voice
- Function generator waveform communication
- Telemetry signal monitoring and processing
- Remote detection of light intensity and environment temperature
- Communication range verification: indoor 35m, outdoor 100m
- Frequency selection and modulation experiments
Standard Accessories
- Banana Connecting Cable
- Instructor manual & student workbook
- Circuit diagram (block + schematic)
- Patch cords
- Multimeter probes
- Power cable
Warranty: One Year
